Item No.15.6寸
Size (mm)356.62*211
Working voltage (V) 27.5min--34.5（max)
Working current (mA)480
Brightness (mcd) 18800
Chromatic coordinatesX:0.27-0.31/Y:0.25-0.31
Uniformity (≥%)80
Working temperature (℃)-40+90
Application areasIn-vehicle instrument display
Item No.15.6寸
Size (mm)335.6*197.32
Working voltage (V) 27.5min--34.5（max)
Working current (mA)480
Brightness (mcd) 19200
Chromatic coordinatesX:0.27-0.31/Y:0.25-0.31
Uniformity (≥%)80
Working temperature (℃)-40+90
Application areasIn-vehicle instrument display
Item No.15.6寸
Size (mm)362.6L*214.7W*6.8T
Working voltage (V) 23.13-28.53
Working current (mA)300*2=600
Brightness (mcd) 15610
Chromatic coordinatesX:0.27-0.33/Y:0.28-0.34
Uniformity (≥%)80
Working temperature (℃)-30+80
Application areasNew-energy display, etc.
Item No.12.6寸
Size (mm)271.7*216.5
Working voltage (V) 18min--24（max)
Working current (mA)480
Brightness (mcd) 11000
Chromatic coordinatesX:0.27-0.31/Y:0.265-0.31
Uniformity (≥%)80
Working temperature (℃)-40+90
Application areasIn-vehicle instrument display
Item No.12.3寸
Size (mm)302.93*123.11*9.98
Working voltage (V) /
Working current (mA)/
Brightness (mcd) 120(模組)
Chromatic coordinates/
Uniformity (≥%)80
Working temperature (℃)-30-+85
Application areasMini car instrument display
Item No.9.9寸
Size (mm)250.22*118.49*5.82
Working voltage (V) 18
Working current (mA)360
Brightness (mcd) 12000
Chromatic coordinatesX:0.26-0.32/Y:0.26-0.32
Uniformity (≥%)80
Working temperature (℃)-30+75
Application areasDisplay on the rearview mirror of Truck A - pillar
Note: Product pictures are for reference only, product size, luminous color, luminous brightness, etc. can be customized on request
