Item No.10.1寸
Size (mm)228.66*148.3*4.35
Working voltage (V) 16.2-20.3
Working current (mA)360
Brightness (mcd) 21500
Chromatic coordinatesX:0.29-0.35/Y:0.29-0.35
Uniformity (≥%)80
Working temperature (℃)-30-+80
Application areasDisplay of Industrial Equipment
Item No.10.1寸
Size (mm)229.76*154.21*6.10
Working voltage (V) 24V(typ)-27.6V(max)
Working current (mA)180
Brightness (mcd) 9000
Chromatic coordinatesX:0.265-0.33/Y:0.26-0.345
Uniformity (≥%)80
Working temperature (℃)-20+80
Application areasDisplay of communication equipment
Item No.8.8寸
Size (mm)64.1*231.2*4.98
Working voltage (V) 13.0-16.5
Working current (mA)180
Brightness (mcd) 13000
Chromatic coordinatesX:0.27-0.33/Y:0.28-0.34
Uniformity (≥%)80
Working temperature (℃)-30-+85
Application areasGame console display screen
Item No.8.0寸
Size (mm)184.21L*114.8W*4.5T
Working voltage (V) 8.1-9.9
Working current (mA)400
Brightness (mcd) 15120
Chromatic coordinatesX:0.27-0.33/Y:0.27-0.33
Uniformity (≥%)80
Working temperature (℃)-20 ~ +70
Application areasIndustrial control, new-energy display, etc.
Item No.8.0寸
Size (mm)114.5*184.0*2.43
Working voltage (V) 18.9-23.8
Working current (mA)60
Brightness (mcd) 7500
Chromatic coordinatesX:0.27-0.31/Y:0.28-0.32
Uniformity (≥%)80
Working temperature (℃)-20-+70
Application areasTablet and commercial display.
Item No.7.0寸
Size (mm)164.2*103.2*3.1
Working voltage (V) 8.1-10.2
Working current (mA)180
Brightness (mcd) 10000
Chromatic coordinatesX:0.275-0.325/Y:0.295-0.345
Uniformity (≥%)75
Working temperature (℃)-20-+70
Application areasDisplay of Industrial Equipment
Note: Product pictures are for reference only, product size, luminous color, luminous brightness, etc. can be customized on request
